Upgrade your audio and video entertainment experience with PowerQuest. The PowerQuest’s power filtration removes more noise and distortion than most power conditioners, dramatically improving your system’s performance. Unlike traditional surge protectors, PowerQuest devices feature Non-Sacrificial Surge Protection, which prevents both high voltage and high current from damaging your equipment, while ensuring that your PowerQuest device won’t fail over time. See and hear everything as it was intended with PowerQuest.
Specifications
Surge Protection: Non-Sacrificial – Nothing to damage with repeated 6000V/3000A input surge tests, which is the maximum that can survive a building’s AC electrical panel.
Ultra-Linear Filters:
- 4K/8K Video Optimized Outlet: In addition to the Ultra-Linear Filters, these outlets offer additonal Noise-Dissipation technology to maximize TV performance.
- Differential-Mode Noise Dissipation: In excess of 22 dB reduction from 30kHz-1GHz.
- Common-Mode Noise Dissipation: In excess of 22 dB reduction from 30kHz-100MHz.
Filter linearized for dynamic (rising) line impedance with frequency from 0.05Ohms (source) and 10 to 50 Ohm load, (system current dependent)
Extreme Voltage Shutdown: 270VAC – Will open the main power circuit relay within less than 0.25 seconds, automatically resets once the incoming power is within a safe range.
Maximum Input Current: 16 amps RMS
8 Outlets:
- 2 x 4K/8K Video Optimized Linear Filter Outlet
- 2 x High-Current Outlet
- 4 x Ultra-Linear Filter Outlets
USB Charge Capacity: 4x ports – Total capacity 4.8 amps
Signal Line Protection: Network
AC Power Cable Length: 2.1m
Dimensions: 393mm x 80mm x 188mm
Weight: 2.5kg
Grading: New & Sealed
